Juki DDL-9000C Series

JUKI DDL-9000C – Digital precision for professional sewing
The JUKI DDL-9000C series combines powerful performance with digital control for top-class sewing. With digitally controlled vertical and horizontal feed, you can easily fine-tune the settings directly via the panel – and save them for future jobs. An energy-efficient, quiet and reliable machine that delivers consistent sewing quality and a smoother workflow, regardless of material or industry.

  • Automatic thread trimmer
  • Stitch length up to 5 mm
  • Sewing speed up to 5000 stitches/min
Download PDF

Technical Specification

Model: DDL-9000C-SS / DDL-9000C-SH / DDL-9000C-MS / DDL-9000C-HS
• Area of application:
  • DDL-9000C-SS: Lightweight fabrics
  • DDL-9000C-SH: Medium-weight materials
  • DDL-9000C-MS: Medium-weight materials
  • DDL-9000C-HS: Heavyweight materials
• Sewing speed:
  • Max. 5,000 stitches/min for SS, MS
  • Max. 4,500 stitches/min for SH, HS
• Maximum stitch length:
  • SS, SH: 5 mm
  • MS, HS: 4 mm
• Press foot lift:
  • With knee lift: 13 mm
  • Manual: 5.5 mm
• Feeding mechanism: Standard feed
• Stitch formation: Lock stitch (shuttle stitch)
• Needle type:
  • DDL-9000C-SS, MS: DB×1 (#11) / 134 (Nm75)
  • DDL-9000C-SH, HS: DB×1 (#19) / 134 (Nm120)
• Lubrication system: Dry machine (no traditional oil tray)
• Gripper:
  • SS, MS: Standard size
  • SH, HS: Large gripper
• Wire tension: Electronically controlled
• Feeding mechanism: Direct drive feed
• Energy consumption:
  • Equipped with JUKI's newly developed direct drive motor
  • Compatible with AC 100V-240V (automatically adjusted power supply)

Product description

Juki DDL-9000C Series – Digitalised Industrial Sewing Machine for Superior Sewing

Are you looking for an energy-efficient, high-performance, precision industrial sewing machine that delivers perfect sewing quality every time? Then the Juki DDL-9000C Series is the obvious choice.

This 1-needle direct drive high-speed lockstitch machine is designed to meet the high demands of garment manufacturing, tailoring, studios, theatre/opera, schools and laundries, as well as many other industries where quality and efficiency are crucial.

Thanks to digitalised vertical and horizontal drive, you can easily adjust the feed directly on the panel to adapt the settings to the material you are working with. Digitisation also makes it possible to store optimal settings for different materials, which ensures stable sewing quality and saves time when switching between products.

With the Juki DDL-9000C, you get a machine that not only delivers perfect seams – it also streamlines your work and reduces manual adjustments.

Description

  • Automatic thread trimmer
  • Thread wiper
  • Presser foot lift up to 15 mm
  • Forward and reverse function
  • Stitch length up to 5 mm
  • Sewing speed up to 5000 stitches/min

Supplied complete with

  • Table
  • Stand
  • Built-in motor with panel

Included features:

  • Automatic wire cutting
  • Automatic thread cutter
  • Electronic stitch length adjustment
  • Automatic presser foot lift

Category:

Industrial sewing machines

Tags:

1-Needle Lockstitch, Juki

Want to know more?

Contact our sales team

From idea to finished product

Whether you want to sew curtains, upholstery or details in leather and technical textiles, our industrial sewing machines deliver durable seams with high precision. Here are some examples of what you can achieve when creativity meets technology.
