Juki LU-2810
JUKI LU-2810 Series – Sewing power for large and heavy work
The LU-2810 series is designed for industrial sewing of large products and extra heavy materials. With combined underfeed, needle feed and alternating top feed, as well as a powerful vertical hook, these machines deliver stable sewing with high precision. Choose between the standard LU-2810 model or the LU-2810-7 with automatic thread trimming – both with extra high arm, wide work surface and robust construction. A reliable solution for production where strength, space and operational reliability are a must.
- Presser foot lift up to 20 mm
- Stitch length up to 9 mm
- Sewing speed up to 3,000 stitches/min
Technical Specification
| LU-2810-7 (1-needle machine with automatic thread cutter): | |
|---|---|
| • Maximum sewing speed: | 3,000 stitches/min |
| • Maximum stitch length: | 9 mm |
| • Stitch length adjustment: | 2-step adjustment knob |
| • Presser foot height: |
|
| • Automatic lift: | Included as standard |
| • Alternative vertical movement: | 1–9 mm |
| • Setting method for optional vertical movement: | Large adjustment knob |
| • DL unit: | Included as standard |
| • Wire tension: | Single/Double voltage |
| • Gripper: | Vertical axis, 2-fold capacity |
| • Micro-adjustment of bottom feed: | Included as standard |
| • Needle: | 135×17 Nm160 (Nm125–Nm180) |
| • Wire: | #30–#5, B46–B138, Min. 60/3–20/3 |
| • Lubrication: | Automatic (Tank system) |
| • Single-press reverse feed button: | Included as standard |
| • Hand switch: | Multifunctional 6-wire switch |
| • Safety mechanism: | Included as standard (reset with the push of a button) |
| • Power supply / Power consumption: | Single-phase 100–120V / 200–240V, three-phase 200–240V / 180VA (with automatic wire cutter) |
| • Machine weight: | 61 kg |
| LU-2810 (1-needle machine): | |
| • Maximum sewing speed: | 3,000 stitches/min |
| • Maximum stitch length: | 9 mm |
| • Stitch length adjustment: | 1-step adjustment knob |
| • Alternative vertical movement: | 1–9 mm |
| • Wire tension: | Double excitement |
| • Gripper: | Vertical axis, 2-fold capacity |
| • Micro-adjustment of bottom feed: | Included as standard |
| • Needle: | 135×17 Nm160 (Nm125–Nm180) |
| • Wire: | #30–#5, B46–B138, Min. 60/3–20/3 |
| • Lubrication: | Automatic (Tank system) |
| • Machine weight: | 56 kg |
| Note: "Stitch/min" stands for stitches per minute.: |
Product description
LU-2810 Series – Industrial sewing machines for large products and extra heavy materials
Are you looking for an industrial sewing machine that delivers precision, power and durability for truly demanding sewing tasks? The LU-2810 Series is the perfect solution for those who work with large products and extra heavy materials. With advanced shuttle sewing technology, underfeed, needle and alternating top feed, and a large vertical hook, these machines deliver outstanding performance and consistent sewing even in the most challenging materials.
LU-2810
With a high and long arm and a wide machine bed, you get optimal working space and improved usability. Perfect for those who need a powerful and reliable machine for industrial production.
LU-2810-7 – With automatic thread trimmer
This model is equipped with an automatic thread trimmer and is ideal for sewing car seats, sofas and bags. Its functionality has been significantly improved, making it ideal for the production of large and heavy materials where precision and efficiency are crucial.
Description
- Large vertical looper
- Presser foot lift up to 20 mm
- Stitch length up to 9 mm
- Sewing speed up to 3,000 stitches/min
Supplied complete with
- Table
- Stand
- Built-in motor with panel
